Quick steam in 5 minutes after cold start
The original design of the high-speed steam generators as water tube boilers offers the advantage of providing steam at very short notice - with high operational reliability at the same time due to the low water volume of the tube coil.
- UNIVERSAL TC steam boiler: Steam output of up to 2,000 kg/h as a single unit
- Up to 16,000 kg/h in series connection
- Multiple units in cascade connection for flexibility and economy
- Reduced installation time and costs
- Pre-tested on our own test bench at the factory
Efficient & economical
Modulating output adjustment: Steam is just as reliably available during peak-load times as periods with less steam demand.
Space-saving
The oil fired steam boiler from CERTUSS requires little space and can also operate with gas, making it ideal for installation in small working areas.
No permit required for size V
High operational reliability thanks to the water tube boiler design. Steam boilers from CERTUSS don't get hot to the touch thanks to 3-fold air insulation.
Universal TC — Steam generator for gas / oil
| Size IV | Size V | Size VI | Size VII | |
|---|---|---|---|---|
| Steam output | 500 — 600 kg/h | 700 — 850 kg/h | 1.000 — 1.300 kg/h | 1.500 — 2.000 kg/h |
| Heat output | 328 — 394 kW | 459 — 558 kW | 656 — 853 kW | 984 — 1.320 kW |
| Max. rated thermal input | 364 — 436 kW | 509 — 619 kW | 778 — 957 kW | 1.091 — 1.454 kW |
| Height / Width / Depth | 1.985 / 955 / 1.725 mm | 2.290 / 1.160 / 1.930 mm | 2.535 / 1.275 / 2.125 mm | 2.675 / 1.420 / 2.415 mm |
| Min. / Max. operating pressure | 6 / 8 — 29 bar | 6 / 8 — 29 bar | 6 / 8 — 29 bar | 6 / 8 — 29 bar |
| Max. perm. overpressure | 10 — 32 bar | 10 — 32 bar | 10 — 32 bar | 10 — 32 bar |
Fail-safe 24/7 steam for the Hucknall aviation site
CERTUSS has supplied Rolls-Royce in Hucknall, Great Britain with a new steam system for the anodizing process. The company's old steam system proved to be inefficient. The new system from CERTUSS offers energy-efficient steam supply in 24/7…
